Short Description
 Model No.: LP 14 FT 02    Hits: 1235
China Aluminium Extruded Finned Tube: ASME SA179 Aluminium AL-1060 Finned Tubes, Seamless, 1 Inch, 10M, BWG 11, THK 0.25-0.45mm, for Heat Exchangers.

Key Specifications / Features

Keywords: Finned Tube, Seamless, OD: 25.4mm, BWG: 11 (Thk: 3.0148).
SA179 Materials, Extruded Fin Tube 1" Finned Per Inch (FPI): 11, Fin Diameter: 57.15.
Length: 10006mm.
Finned Tube OD: 25-88 mm.
Fin Thickness: 0.25-0.45 mm.
Fin Pitch: to your requirement.
Fin Material: Aluminium AL-1060.
Base Tube Material: Any metallic material.

Manufacture:
A core tube is fitted into an aluminium primary tube. This assembly is then fed into the triple-spindle finning machine. Three special multi-disc packs extrude the aluminium tube into helical high fins while reducing the inner diameter to give firm pressure contact with the core tube.

Application:
*Air cooling unit.
*Product coolers - gas, chemicals, petrochemicals, oil etc.
*Heat exchangers.

ASME SA179 Aluminium Extruded Finned Tube 1 Inch parameter:
Size NPS Wall Thickness Pipe I.D. Weight per Foot  Schedule    Section     Modulus  Gallon Capacity Per Linear Foot
1



0.133 1.049 1.68 40 0.1328 0.0449
0.179 0.957 2.17 80 0.1606 0.0374
0.250 0.815 2.85 160 0.1904 0.0271
0.358 0.599 3.66   0.2136 0.0146
